Single Serat Optik Transceivers 10/100/1000Mbps Media Converter
Spesifikasi
Kadar | menyesuaikan diri10/100/1000M |
Protokol disokong | IEEE802.3/IEEE802.3Uetc. |
Fibertype | singlefiber |
Opticmode | mod tunggal |
Transmissionmode | separuh/fullduplex |
Ethernetinterface | RJ45 |
Opticinterface | SC/FC/ST |
Opticwavelength | 1310/1550nm,1490/1550nm |
BER | <1> |
MTBF | 3years |
Kuasa | 2.5W |
Powersupply | AC220V/0.5A,DC-48V/0.5A,DC5V/1A |
Jenis plag | Euro Standard, Standard Amerika, Uk Standard, dll |
Jawatankuasa Kerja | Normal 0~50°C atau Industri -40~85°C |
Kekejaman kerja | 5%-95% |
Storan | -40°C~70°C |
Keisyerhan Penyimpanan | 5%~95%(tidak mempekatakan) |
Berat badan | 0.38KG |
Dimensi | 229x122x50mmforpacking,94x70.6x26.5mmfordevice |
Menempah maklumat
Nombor Bahagian | Serat Optik | Panjang gelombang | Kuasa | Sensitiviti Rx | Mencapai | Kerugian Dibenarkan |
HTF-1110ss-20A/B | Mod tunggal | 1310/1550nm | -6~-1db | -22db | 20km | 22db |
HTF-1110ss-40A/B | Mod tunggal | 1310/1550nm | -5~0db | -22db | 40km | 23db |
HTF-1110ss-60A/B | Mod tunggal | 1490/1550nm | 0~2db | -25db | 60km | 25db |
HTF-1110ss-80A/B | Mod tunggal | 1490/1550nm | 0~2db | -25db | 80km | 25db |
